| HR980 | VARIOUS YORK/TECUMSEH (CL 1118HC thru CL 6643) |
| VARIOUS YORK/TECUMSEH (CL 0619 thru CL 0697) |
CLUTCHES / YORK-TECUMSEH-FEMSA DIMENSION CHARTS Rev. 03-17-04
| HR980 COMPRESSOR | VOLTAGE | NO. OF GROOVES | DIMENSIONS (CLICK HERE TO SEE DIMENSION EXAMPLE) |
NEW PART NO. | REMAN PART NO | |||||||
| A | B | C | D | E | X | Y | XX | |||||
| HR980 | 12V | 1 |  OE:YB312, YB288, YB338 |
|||||||||
| HR980 | 12V | 2 |  OE:YB309, YB274, YB275 |
|||||||||
| HR980 | 12V | 2 |  OE:YB318, YB288, YB290A |
|||||||||
| HR980 | 12V | 1 |  OE:YB309, YB294A, YB281 YB312A, YB288A, YB342A |
|||||||||
| HR980 | 12V | 1 |  OE:YB319A, YB288A, YB290A |
|||||||||
| HR980 | 12V | 2 |  OE:YB313A, YB288A, YB290A |
|||||||||
| HR980 | 12V | 6 |  OE:YB317, YB288, YB342 YB317A, YB288A, YB290A YB317A, YB288A, YB355A |
|||||||||
| HR980 | 12V | 6 |  OE:YB319A, YB288, YB355 YB354A, YB288A, YB355A |
|||||||||
| VARIOUS YORK / TECUMSEH COMPRESSORS Back to Top |
VOLTAGE | NO. OF GROOVES | DIMENSIONS (CLICK HERE TO SEE DIMENSION EXAMPLE) |
NEW PART NO. | REMAN PART NO. | |||||||
| A | B | C | D | E | X | Y | XX | |||||
| VARIOUS | 12V | 1 |  OE: AUTOCAR (03-1104978) FREIGHTLINER (03-1104978) KYSOR (402011, 402422, 402914) KYSOR (402901, 402033, 402404) MACK (1MX-243) PETERBILT (18-2441) RED DOT (75R-2402) VOLVO WHITE (03-1104978) WESTERN STAR (02-7135903) WESTERN STAR (891422B) |
|||||||||
| VARIOUS | 12V | 1 |  OE: AUTOCAR (03-1104968) KENWORTH (K332-28, K332-45) KYSOR (402046, 402421, 402913) PETERBILT (18-1211, 18-1222) RED DOT (75R-1952) WESTERN STAR (562292, 571136) |
|||||||||
| VARIOUS | 12V | 1 |  OE: KYSOR (402050, 402418, 402910, 402909) WESTERN STAR (02-7074277) |
|||||||||
| VARIOUS | 12V | 1 |  OE: FREIGHTLINER (A22-10582, A22-22499, 02-701496) KENWORTH (K332-40, K332-48) KYSOR (402036, 402403, 402900) MACK (1MX-3217) PETERBILT (18-1843) RED DOT (75R-1652) |
|||||||||
| VARIOUS | 12V | 1 |  OE: KYSOR (402067, 402411, 402903) RED DOT (75R-1502) VOLVO WHITE (61103-0044) |
|||||||||
| VARIOUS | 12V | 1 |  OE: AUTOCAR (17C01283) HOLLEY (91-270309) KENWORTH (K332-31, K332-46) KYSOR (402043, 402413, 402905) MACK (1MX-3219) PETERBILT (18-1209) RED DOT (75R-4202) |
|||||||||
| VARIOUS | 12V | 1 |  OE: KYSOR (402051, 402414, 402906) MARMON (0109-00019-001) PETERBILT (18-1208) RED DOT (75R-2702) |
|||||||||
| VARIOUS | 12V | 1 |  OE: FREIGHTLINER (A22-11669, 02-7001224) KENWORTH (K332-12, K332-26, K332-43) KYSOR (402037, 402420, 402912) MACK (208RD-31) PETERBILT (18-1212) RED DOT (75R-1802) VERSATILE (19107) |
|||||||||
| VARIOUS | 12V | 1 |  OE: FREIGHTLINER (A22-10795) KENWORTH (K332-32) KYSOR (402042, 402425, 402916) RED DOT (75R-2552) WESTERN STAR (892881A, 892960A) |
|||||||||
| VARIOUS | 12V | 1 |  OE: AUTOCAR (03-1104964) KYSOR (402062, 402415, 402907) RED DOT (75R-2852) WESTERN STAR (892880A) |
|||||||||
| VARIOUS | 12V | 1 |  OE: FREIGHTLINER (03-1105004) KYSOR (402056, 402423) MASSEY FERGUSON (274363M91) |
|||||||||
| VARIOUS | 12V | 1 |  OE: FREIGHTLINER (A22-11670) HOLLEY (91-270305) KYSOR (402038, 402952, 402075) |
|||||||||
| VARIOUS | 12V | 1 |  OE: HOLLEY (91-270103) MOTORCRAFT (YB163, YB162), (YB167, YB162), (YB200, YB162) |
|||||||||
| VARIOUS | 12V | 1 |  OE: HOLLEY (91-270306) KENWORTH (K332-25, K332-15, K332-21) KYSOR (402503, 402545, 402919) MACK (1MXA-1279, 1MX-3268) PETERBILT (18-1214) RED DOT (75R-4652) |
|||||||||
| 24V | 2 | 6" |  CL 0698O |
|||||||||
